Durable Aluminum Cladding Steel Production Setup

   Aluminum Cladding Steel Production Line    1. Production line introduction of Aluminum Clad Steel Wire Line The ACS Continuous Cladding Extrusion Line adopts a tangential continuous cladding process, which enables the continuous coating of aluminum onto the surface of pre-treated steel wire. Subsequently, the bi-metal synchro deforming technology is applied to draw the wire to the desired dimensions. ACS wire produced via this method complies with both IEC and ASTM Standards.     2. Main technical data of metal cladding line for steel Extrusion wheel size:                         340 mm Main machine max. rotary speed:    16 rpm Power supply:                                   380V  50HZ  Main motor power:                        200 kW/1500rpm Steel wire diameter:                        3~7mm Max. cladding speed:                    180 m/min Aluminum rod diameter:               9.5mm Take-up load:                               ≤8t Center height:                             12…
