Precision Square Flange Bearing Unit

UCF207 Square Flange Bearing Unit is a complete Unit Bearing Assembly composed of UC207 insert bearing and F207 Flanged Bearing Housing, regarded as a robust Industrial Bearing Unit for industrial transmission. It has a 35mm bore, made of GCr15 bearing steel and HT200 grey cast iron housing, equipped with double-layer NBR oil seal and set screw locking mechanism. This Square Flange Bearing Unit achieves ±2° self-aligning performance to compensate shaft alignment error, cutting friction and boosting transmission efficiency. Pre-filled with lithium base grease, its standard operating temperature ranges from -20℃ to 100℃. Adopting P0 precision grade, the bearing supports continuous running speed up to 2600r/min with reliable load capacity. The rigid cast iron housing delivers excellent vibration resistance and stable locking, minimizing unexpected shutdowns. As an integrated Unit Bearing Assembly, it features standard interchangeable dimensions and simple flange mounting. Widely utilized…
