Semi-Automatic Diecutting And Creasing Machine

Technical parameter Item Parameters Model BMY-1300 Die cutting type Pressed flat die cutting(Lower side is movable while upper side is unmovable) Max paper transmitting size 1320*980mm Min paper transmitting size 400*500mm Max die cutting size 1300*960mm Min gripper size 8mm Max die cutting pressure 350N/cm² Paper processed Cardboard        200-2000 gsm   Corrugated board  ≦ 10mm Max die cutting speed 4600 sheets/h Max feeding pile height 1400mm(above the level) Min feeding pile height 1250mm(above the level) Main motor power 11 kw Total power ～13.5 kw Total weight ～13.5 T Overall size 4500*2300*2250mm   (without platform and pre-paper) 6500*4300*2250 System introduction Feeding and Collecting Part l Whole machine is risen making the maximum front pile height up to 1400mm and the back pile height up to 1250mm l At the middle of head install the monitor&nbs…
